Guangdong Elieken Electronic Technology Co.,Ltd.
Model No.: M3-6405U
Packaging: Standard Export Packing.
Transportation: Ocean,Air
Port: Guangzhou
Payment Type: L/C,T/T,Paypal,Others
Incoterm: FOB,CIF,EXW,DDP,DDU
Intel Nuc with wide range of applications
Smooth operation, strong scalability, solid structure, flexible installation, Mini Cpu safety and stability Wide range of applications such as artificial intelligence research and development, fully automated industrial applications. Fanless Mini PC software development, machine vision, commercial applications, and more waiting for you to explore.
What can this ElieKen Mini PC Pentium 6405U Windows Linux Desktop Computer do?
Office work: Office, Skype, yahoo, outlook, and all other office requirement support and runs perfect;
Design work: Photoshop, CorelDRAW, Dreamweaver, Illustrator, Flash, In-design, and others
Game playing: support most online games and PC games, like Warcraft, Counter-Strike (CS), support 3D games but this is integrated graphic not independent cards, so don't play very high-grade 3D games.
Entertainment: support blu ray 1080P and 4k video play, XBMC, and others
| General | |
| CPU | Onboard Intel Skylake 14nm CPU Intel Pentium 6405U 2.4GHz Dual Core Four Threads 2MB cache TDP 15W . |
| Core (FSB) | 100MHz |
| CPU Technique | 22nm |
| L3 Cache | 2MB SmartCache, CPU Integrated |
| BOIS | AMI BIOS, ACPI supported Support calls on function automatically Support Wake-On-LAN |
| Chipset | Intel Commet Lake |
| Memory | 1* SO-DIMM DDR4 Slot Support 4GB/8GB/16GB/32GB Dual Channel, DDR4-2400MHZ |
| Storage | SSD: 8G/16G/32G/64G/128G/256G/512G/1TB HDD: 160G/320G/500G/1TB |
| Operating System | Windows 7/Windows 8/Windows 10/Linux |
| Audio | ALC897 chip, 7.1 channel sound Intel Lynx Point-LP HDA |
| Network | Onboard Realtek RTL8168E PCI-E Gigabit Ethernet NIC Onboard RTL8111DL10/100Mbps/1000Mbps BaseT LAN |
| Video | Intel® UHD Graphics |
| I/O port | |
| front panel ports | 2*USB2.0, 4*USB3.0, 1* Power indicator and switch |
| Backside ports | 1*HDMI, 1*VGA, 1*LAN, 1*MIC, 1*SPK, 2*WiFi antennas |
| Internal ports | 1*M-SATA3.0 port, support 6Gb/s 1*SATA3.0 port, support 6Gb/s 1*mini-PCIE port(WIFI&Bluetooth) |
| Power and Working Environment | |
| Input | DC100-240V AC/50-60Hz |
| Output | DC 12V~19V/5A |
| Operating Temperature | 0/70 Centigrade(32F~140F) |
| Storage Temperature | -20/+85 Centigrade |
| Relative Humidity | 0%~90% (non-condensing) |
| Energy-saving | Support Energy-saving technology, Speedstep |
| 64 bit computing | Support 64 bit computing |
| Virtualization | Intel VT-x |
| Hyper-threading | Support Hyper-Threading |
| Product Dimension & Details | |
| Size | 174*127*37MM |
| Weight | 1.5KG |
| Consumption | 15W |
| Shell | Silver color aluminum alloy |
| Package Content | Mini PC device, power adapter, a VESA mount, dual WiFi antennas(optional), a HDMI cable( as a gift), a Screw Bag, Warranty Card |
Product Categories : Mini PC > Mini PC Core I5
